Modern technologies now use calibrated injection systems. Each model The performance is maximized because of the millimetric precision with all the other components. Conventional systems still use fragile valves with moving parts that are not calibrated to work at low temperatures. The calibrated flow rater is not affected by varying temperatures.
All the pool heat pumps are equipped with unique patented features that increase the efficiency and reduce the electrical consumption, and this, even at low outdoor temperatures due to the calibrated injection system.
The compressors used by Turcotte are of Japanese technology. These compressors, rotary and scroll, are very silent and do not require compressor blankets in order to reduce noise and vibration.
Today’s aquatic installation facilities require the usage of variable-speed or two-speed pumps. Our heat pumps are designed to operate at low rate with these modern circulation pumps, allowing you to save electricity.
| MODELS | Stratos 60 | Stratos 65 | Stratos 80 | Stratos 105 | |
|---|---|---|---|---|---|
| Above-ground pools Application |
15′ - 18′ - 21' | 24′ - 27' | 30′ | 33' | |
| In-ground pools Application |
10′ X 20′
|
12′ X 24′ |
14’x28′
|
16' x 30' 16' x 32' 18' x 36' |
|
| Capacity BTU/h | 59,000 | 65,000 | 75,000 | 105,000 | |
| BTU Water/Air/Humidity 80/80/80 Degres F | 51 900 | 57 000 | 86 200 | ||
| COP Water/Air/Humidity 80/80/80 Degres F | 6,1 | 6,4 | 6 | ||
| BTU Water/Air/Humdity 80/80/63 Degres F | 47 500 | 52 500 | 80 000 | ||
| COP Water/Air/Humidity 80/80/63 Degres F | 5,7 | 6 | 5,5 | ||
| BTU Water/Air/Humidity 80/50/63 Degres F | 33 500 | 36 500 | 56 500 | ||
| COP Water/Air/Humidity 80/50/63 Degres F | 4 | 4,4 | 4 | ||
| Compressor Type | ROTARY | ROTARY | ROTARY | ||
| Operating Amperage | 10 | 12 | 18 | ||
| Water Flow (GPMUS) | 8 TO 80 | 9 TO 80 | 10 TO 80 | ||
| Electrical Connections Volts / Phase / Hz | 240/1/60 | ||||
| Circuit Breaker (amps) | 20 | 30 | 40 | ||
| Length / Height / Width (inches) | 40/24/14 | 40/28/19 | 40/28/19 | ||
| Net Weight Pounds (kg) | 115 (52) | 130 (59) | 150 (68) | ||
